CNC Engraving Machine(QL-1212)

• Place of Origin:

   China

• Type:

  Others

• Genre:

  Machinery & Equipment

• sCode:

  STPR1433847

• Place of Origin:

  China
• QL-1212 CNC Advertising Machine
  Characteristics:
  1, Germany-High-precision ball screws Preload Consumers gap, the movement to reduce the gap to the minimum.
  2, 4 imports Pai ball linear guides, self-lubricating block so that the direction of force equal to ensure that the mechanical precision and intensity.
  3, the application of the breakpoint memory, guaranteed in the accident (Duandao) or the next day, under processing.
  4, a number of workpiece machining unique way to preserve the original point.
  5, gantry movement, strengthen the surface, sturdiness and durability, prolonged use of distortion, so that more precise positioning accuracy.
  6, produced not only signs without serrated carving fine, smooth contours clear bottom, and also cut 2 cm plexiglass ease.
  7, the channel bed and casting bed for election

  Machine Model QL-1212
  X.Y working area 1200*1200mm
  Z working area 100mm
  Table 1300*1420mm
  Max. Speed 5m-6m/min
  Max. working speed 2m-3m/min
  Max. feeding height 110mm
  Working delicacy 0.005mm
  Repositioning accuracy 0.05mm
  Command G code*.u00*.mmg*.plt
  Surroundings for software windows98/2000/xp
  Power (spindle is not included) 400w
  Working voltage AC220V/50Hz
  Spindle power 1.5kw
  Spindle rotating speed 0-24000rpm/min
  Drive motor Steper
